Shader on Scroll

gsap.registerPlugin(ScrollTrigger);

// Shared velocity proxy for all canvases
const velocityProxy = { v: 0, s: 0 }; // v = signed, s = strength (0..1)
const clamp = gsap.utils.clamp(-2000, 2000);

// A single ScrollTrigger to compute velocity and tween back to 0
ScrollTrigger.create({
 start: 0,
 end: () => document.documentElement.scrollHeight - window.innerHeight,
 onUpdate(self) {
 const raw = clamp(self.getVelocity()); // px/s-ish
 const norm = raw / 1000; // ~ -1..1
 const strength = Math.min(1, Math.abs(norm));

 if (Math.abs(strength) > Math.abs(velocityProxy.s)) {
 velocityProxy.v = norm;
 velocityProxy.s = strength;
 gsap.to(velocityProxy, {
 v: 0,
 s: 0,
 duration: 0.8,
 ease: "sine.inOut",
 overwrite: true
 });
 }
 }
});

// Vertex shader
const vert = /* glsl */ `
 varying vec2 vUv;
 varying vec2 vUvCover;
 uniform vec2 uTextureSize;
 uniform vec2 uQuadSize;

 void main(){
 vUv = uv;

 // "cover" mapping to preserve aspect ratio
 float texR = uTextureSize.x / uTextureSize.y;
 float quadR = uQuadSize.x / uQuadSize.y;
 vec2 s = vec2(1.0);
 if (quadR > texR) { s.y = texR / quadR; } else { s.x = quadR / texR; }
 vUvCover = vUv * s + (1.0 - s) * 0.5;

 gl_Position = vec4(position, 1);
 }
 `;

// Fragment shader
const frag = `
 precision highp float;

 uniform sampler2D uTexture;
 uniform vec2 uTextureSize;
 uniform vec2 uQuadSize;
 uniform float uTime;
 uniform float uScrollVelocity; // signed -1..1
 uniform float uVelocityStrength; // 0..1, decays to 0

 varying vec2 vUv;
 varying vec2 vUvCover;

 void main() {
 vec2 texCoords = vUvCover;

 // drive distortion amount from velocity strength
 float amt = 0.03 * uVelocityStrength;

 // small wave that doesn’t depend on mouse
 float t = uTime * 0.8;
 texCoords.y += sin((texCoords.x * 8.0) + t) * amt;
 texCoords.x += cos((texCoords.y * 6.0) - t * 0.8) * amt * 0.6;

 // optional directional tint: push R/G/B differently by scroll direction
 float dir = sign(uScrollVelocity);
 vec2 tc = texCoords;

 float r = texture2D(uTexture, tc + vec2( amt * 0.50 * dir, 0.0)).r;
 float g = texture2D(uTexture, tc + vec2( amt * 0.25 * dir, 0.0)).g;
 float b = texture2D(uTexture, tc + vec2(-amt * 0.35 * dir, 0.0)).b;

 gl_FragColor = vec4(r, g, b, 1.0);
 }
 `;

// Build one tiny Three.js scene per frame
document.querySelectorAll(".frame").forEach(initFrame);

function initFrame(frameEl) {
 const renderer = new THREE.WebGLRenderer({ antialias: true, alpha: true });
 frameEl.appendChild(renderer.domElement);
 renderer.outputColorSpace = THREE.SRGBColorSpace;
 renderer.setPixelRatio(Math.min(window.devicePixelRatio || 1, 2));

 const scene = new THREE.Scene();
 const camera = new THREE.OrthographicCamera(-1, 1, 1, -1, 0, 1);
 const geom = new THREE.PlaneGeometry(2, 2);

 const uniforms = {
 uTexture: { value: null },
 uTextureSize: { value: new THREE.Vector2(1, 1) },
 uQuadSize: { value: new THREE.Vector2(1, 1) },
 uTime: { value: 0 },
 uScrollVelocity: { value: 0 },
 uVelocityStrength: { value: 0 }
 };

 const mat = new THREE.ShaderMaterial({
 uniforms,
 vertexShader: vert,
 fragmentShader: frag,
 transparent: true
 });

 const mesh = new THREE.Mesh(geom, mat);
 scene.add(mesh);

 // Load the image for this frame
 const url = frameEl.getAttribute("data-img");
 const loader = new THREE.TextureLoader();
 loader.setCrossOrigin("anonymous");
 loader.load(url, (tex) => {
 tex.colorSpace = THREE.SRGBColorSpace;

 uniforms.uTexture.value = tex;
 uniforms.uTextureSize.value.set(tex.image.width, tex.image.height);
 layout(); // size once we know texture size
 });

 function layout() {
 const { width, height } = frameEl.getBoundingClientRect();
 renderer.setSize(width, height, false);
 uniforms.uQuadSize.value.set(width, height);
 }

 // Animate this canvas
 let last = performance.now();
 function tick(now) {
 const dt = (now - last) * 0.001;
 last = now;
 uniforms.uTime.value += dt;

 // pull shared velocity state into our uniforms
 uniforms.uScrollVelocity.value = velocityProxy.v;
 uniforms.uVelocityStrength.value = velocityProxy.s;

 renderer.render(scene, camera);
 }
 gsap.ticker.add(tick);
}

/* StyleGallery host styles: independent replacement for unavailable shared Pen CSS. */
:root{--color-just-black:#111522;--color-surface-white:#f7f3ec;--color-surface75:#cfccc6;--color-surface50:#898e9f;--color-surface25:#414859;--color-shockingly-green:#95efd2;--color-lt-green:#b5f4da;--color-pink:#fbadce;--color-purple:#897dff;--color-lilac:#b5a1ff;--color-orangey:#ffd28c;--color-blue:#75d8ed;--color-ui-gradient:linear-gradient(135deg,#fbadce,#897dff);--color-ui-gradient-background:linear-gradient(135deg,#fbadce,#897dff);--color-text-gradient:linear-gradient(135deg,#fbadce,#897dff);--gradient-summer-fair:linear-gradient(135deg,#ffd28c,#fbadce);--gradient-lipstick:linear-gradient(135deg,#fbadce,#fc7f8e);--gradient-macha:linear-gradient(135deg,#b5f4da,#75d8ed);--color-grey:#898e9f;--color-grey-dark:#414859;--color-scroll-pink-lt:#fbadce;--color-text-purple:#b5a1ff;--surface50:#898e9f;--light:#f7f3ec;--dark:#111522;--mid:#898e9f}
/* External font programs are omitted; preserve readable fallback typography. */
body,button,input,h1,h2,h3,h4,p,span,div{font-family:inherit}body{font-family:system-ui,sans-serif}code,pre{font-family:ui-monospace,monospace}

window.__STYLEGALLERY_ASSETS__={};
gsap.registerPlugin(ScrollTrigger);
const velocityProxy = { v: 0, s: 0 };
const clamp = gsap.utils.clamp(-2e3, 2e3);
ScrollTrigger.create({
  start: 0,
  end: () => document.documentElement.scrollHeight - window.innerHeight,
  onUpdate(self) {
    const raw = clamp(self.getVelocity());
    const norm = raw / 1e3;
    const strength = Math.min(1, Math.abs(norm));
    if (Math.abs(strength) > Math.abs(velocityProxy.s)) {
      velocityProxy.v = norm;
      velocityProxy.s = strength;
      gsap.to(velocityProxy, {
        v: 0,
        s: 0,
        duration: 0.8,
        ease: "sine.inOut",
        overwrite: true
      });
    }
  }
});
const vert = (
  /* glsl */
  `
 varying vec2 vUv;
 varying vec2 vUvCover;
 uniform vec2 uTextureSize;
 uniform vec2 uQuadSize;

 void main(){
 vUv = uv;

 // "cover" mapping to preserve aspect ratio
 float texR = uTextureSize.x / uTextureSize.y;
 float quadR = uQuadSize.x / uQuadSize.y;
 vec2 s = vec2(1.0);
 if (quadR > texR) { s.y = texR / quadR; } else { s.x = quadR / texR; }
 vUvCover = vUv * s + (1.0 - s) * 0.5;

 gl_Position = vec4(position, 1);
 }
 `
);
const frag = `
 precision highp float;

 uniform sampler2D uTexture;
 uniform vec2 uTextureSize;
 uniform vec2 uQuadSize;
 uniform float uTime;
 uniform float uScrollVelocity; // signed -1..1
 uniform float uVelocityStrength; // 0..1, decays to 0

 varying vec2 vUv;
 varying vec2 vUvCover;

 void main() {
 vec2 texCoords = vUvCover;

 // drive distortion amount from velocity strength
 float amt = 0.03 * uVelocityStrength;

 // small wave that doesn’t depend on mouse
 float t = uTime * 0.8;
 texCoords.y += sin((texCoords.x * 8.0) + t) * amt;
 texCoords.x += cos((texCoords.y * 6.0) - t * 0.8) * amt * 0.6;

 // optional directional tint: push R/G/B differently by scroll direction
 float dir = sign(uScrollVelocity);
 vec2 tc = texCoords;

 float r = texture2D(uTexture, tc + vec2( amt * 0.50 * dir, 0.0)).r;
 float g = texture2D(uTexture, tc + vec2( amt * 0.25 * dir, 0.0)).g;
 float b = texture2D(uTexture, tc + vec2(-amt * 0.35 * dir, 0.0)).b;

 gl_FragColor = vec4(r, g, b, 1.0);
 }
 `;
document.querySelectorAll(".frame").forEach(initFrame);
function initFrame(frameEl) {
  const renderer = new THREE.WebGLRenderer({ antialias: true, alpha: true });
  frameEl.appendChild(renderer.domElement);
  renderer.outputColorSpace = THREE.SRGBColorSpace;
  renderer.setPixelRatio(Math.min(window.devicePixelRatio || 1, 2));
  const scene = new THREE.Scene();
  const camera = new THREE.OrthographicCamera(-1, 1, 1, -1, 0, 1);
  const geom = new THREE.PlaneGeometry(2, 2);
  const uniforms = {
    uTexture: { value: null },
    uTextureSize: { value: new THREE.Vector2(1, 1) },
    uQuadSize: { value: new THREE.Vector2(1, 1) },
    uTime: { value: 0 },
    uScrollVelocity: { value: 0 },
    uVelocityStrength: { value: 0 }
  };
  const mat = new THREE.ShaderMaterial({
    uniforms,
    vertexShader: vert,
    fragmentShader: frag,
    transparent: true
  });
  const mesh = new THREE.Mesh(geom, mat);
  scene.add(mesh);
  const url = frameEl.getAttribute("data-img");
  const loader = new THREE.TextureLoader();
  loader.setCrossOrigin("anonymous");
  loader.load(url, (tex) => {
    tex.colorSpace = THREE.SRGBColorSpace;
    uniforms.uTexture.value = tex;
    uniforms.uTextureSize.value.set(tex.image.width, tex.image.height);
    layout();
  });
  function layout() {
    const { width, height } = frameEl.getBoundingClientRect();
    renderer.setSize(width, height, false);
    uniforms.uQuadSize.value.set(width, height);
  }
  let last = gsap.ticker.time;
  function tick(now) {
    const dt = now - last;
    last = now;
    uniforms.uTime.value += dt;
    uniforms.uScrollVelocity.value = velocityProxy.v;
    uniforms.uVelocityStrength.value = velocityProxy.s;
    renderer.render(scene, camera);
  }
  gsap.ticker.add(tick);
}
addEventListener("load", () => requestAnimationFrame(() => {
  document.querySelector(".frame").scrollIntoView({ block: "center", behavior: "instant" });
  ScrollTrigger.update();
}));

<!--
