Three.js Scroll Waypoints

console.clear();
gsap.registerPlugin(Flip, ScrollTrigger);

let ctx, renderer, scene, camera, mesh, canvasEl;

/*
 makeGradientNoiseTexture() This becomes our texture for the cube.
*/
function makeGradientNoiseTexture() {
 const c = document.createElement("canvas");
 c.width = c.height = 256;
 const g = c.getContext("2d");

 g.fillStyle = (() => {
 const grd = g.createLinearGradient(0, 0, 230, 384);
 grd.addColorStop(0, "#fec5fb"); // color A
 grd.addColorStop(1, "#00bae2"); // color B
 return grd;
 })();
 g.fillRect(0, 0, 256, 256);

 // Subtle grain for texture.
 for (let i = 0; i < 4000; i++) {
 const x = Math.floor(gsap.utils.random(0, 256));
 const y = Math.floor(gsap.utils.random(0, 256));
 const a = gsap.utils.random(0.02, 0.1);
 g.fillStyle = `rgba(0,0,0,${a})`;
 g.fillRect(x, y, 3, 3);
 }

 const tex = new THREE.CanvasTexture(c);
 tex.colorSpace = THREE.SRGBColorSpace;
 tex.anisotropy = 4;
 return tex;
}

/*
 initThree(canvas)
 Sets up a very small Three.js scene that renders into the supplied canvas.
*/
function initThree(canvas) {
 renderer = new THREE.WebGLRenderer({ canvas, antialias: true, alpha: true });
 renderer.outputColorSpace = THREE.SRGBColorSpace;

 scene = new THREE.Scene();
 camera = new THREE.PerspectiveCamera(45, 1, 0.1, 100);
 camera.position.set(0, 0, 3);

 // Square cube with our gradient noise texture
 const mat = new THREE.MeshBasicMaterial({ map: makeGradientNoiseTexture() });
 mesh = new THREE.Mesh(new THREE.BoxGeometry(1, 1, 1), mat);
 scene.add(mesh);

 // Render on the GSAP ticker so ScrollTrigger timing stays in sync
 gsap.ticker.add(render);
 onResize();

 buildTimeline();
}

/*
 render() the scene.
*/
function render() {
 if (!renderer) return;
 renderer.render(scene, camera);
}

/*
 onResize()
*/
function onResize() {
 if (!renderer || !canvasEl) return;
 const r = canvasEl.getBoundingClientRect();
 const dpr = Math.min(window.devicePixelRatio || 1, 2);
 renderer.setPixelRatio(1);
 renderer.setSize(
 Math.max(1, r.width * dpr),
 Math.max(1, r.height * dpr),
 false
 );
 camera.aspect = (r.width || 1) / (r.height || 1);
 camera.updateProjectionMatrix();
}

/*
 buildTimeline()
 Flip moves the canvas between your marker targets
 while we rotate the cube in the same timeline.
*/
function buildTimeline() {
 ctx && ctx.revert(); // clean teardown for resizes
 ctx = gsap.context(() => {
 const s2 = Flip.getState(".second .marker");
 const s3 = Flip.getState(".third .marker");

 const tl = gsap.timeline({
 scrollTrigger: {
 start: 0,
 end: "max",
 scrub: 2
 }
 });

 // Hop to second marker and rotate the cube
 tl.add(Flip.fit(canvasEl, s2, { duration: 1, ease: "none" }), 0)
 .to(
 mesh.rotation,
 { x: `+=${Math.PI}`, y: `+=${Math.PI}`, duration: 1, ease: "none" },
 "<"
 )

 // A little breathing room between hops
 .addLabel("mid", "+=0.5")

 // Hop to third marker and rotate again
 .add(Flip.fit(canvasEl, s3, { duration: 1, ease: "none" }), "mid")
 .to(
 mesh.rotation,
 { x: `+=${Math.PI}`, y: `+=${Math.PI}`, duration: 1, ease: "none" },
 "<"
 );
 });
}

/*
 build()
 Creates the canvas in the starting container and kicks off the scene.
*/
function build() {
 ctx && ctx.revert();
 const start = document.querySelector(".container.initial");
 if (!canvasEl) {
 canvasEl = document.createElement("canvas");
 canvasEl.className = "box";
 start.appendChild(canvasEl);
 initThree(canvasEl);
 } else {
 buildTimeline();
 }
}

// Boot it up
build();

// Keep things laid out correctly when the layout changes
addEventListener("resize", () => {
 onResize();
 buildTimeline();
});

/* StyleGallery host styles: independent replacement for unavailable shared Pen CSS. */
:root{--color-just-black:#111522;--color-surface-white:#f7f3ec;--color-surface75:#cfccc6;--color-surface50:#898e9f;--color-surface25:#414859;--color-shockingly-green:#95efd2;--color-lt-green:#b5f4da;--color-pink:#fbadce;--color-purple:#897dff;--color-lilac:#b5a1ff;--color-orangey:#ffd28c;--color-blue:#75d8ed;--color-ui-gradient:linear-gradient(135deg,#fbadce,#897dff);--light:#f7f3ec;--dark:#111522;--mid:#898e9f}
/* External font programs are omitted; preserve readable fallback typography. */
body,button,input,h1,h2,h3,h4,p,span,div{font-family:inherit}body{font-family:system-ui,sans-serif}code,pre{font-family:ui-monospace,monospace}

window.__STYLEGALLERY_ASSETS__={};
console.clear();
gsap.registerPlugin(Flip, ScrollTrigger);
let ctx, renderer, scene, camera, mesh, canvasEl;
function makeGradientNoiseTexture() {
  const c = document.createElement("canvas");
  c.width = c.height = 256;
  const g = c.getContext("2d");
  g.fillStyle = (() => {
    const grd = g.createLinearGradient(0, 0, 230, 384);
    grd.addColorStop(0, "#fec5fb");
    grd.addColorStop(1, "#00bae2");
    return grd;
  })();
  g.fillRect(0, 0, 256, 256);
  for (let i = 0; i < 4e3; i++) {
    const x = Math.floor(gsap.utils.random(0, 256));
    const y = Math.floor(gsap.utils.random(0, 256));
    const a = gsap.utils.random(0.02, 0.1);
    g.fillStyle = `rgba(0,0,0,${a})`;
    g.fillRect(x, y, 3, 3);
  }
  const tex = new THREE.CanvasTexture(c);
  tex.colorSpace = THREE.SRGBColorSpace;
  tex.anisotropy = 4;
  return tex;
}
function initThree(canvas) {
  renderer = new THREE.WebGLRenderer({ canvas, antialias: true, alpha: true });
  renderer.outputColorSpace = THREE.SRGBColorSpace;
  scene = new THREE.Scene();
  camera = new THREE.PerspectiveCamera(45, 1, 0.1, 100);
  camera.position.set(0, 0, 3);
  const mat = new THREE.MeshBasicMaterial({ map: makeGradientNoiseTexture() });
  mesh = new THREE.Mesh(new THREE.BoxGeometry(1, 1, 1), mat);
  scene.add(mesh);
  gsap.ticker.add(render);
  onResize();
  buildTimeline();
}
function render() {
  if (!renderer) return;
  renderer.render(scene, camera);
}
function onResize() {
  if (!renderer || !canvasEl) return;
  const r = canvasEl.getBoundingClientRect();
  const dpr = Math.min(window.devicePixelRatio || 1, 2);
  renderer.setPixelRatio(1);
  renderer.setSize(
    Math.max(1, r.width * dpr),
    Math.max(1, r.height * dpr),
    false
  );
  camera.aspect = (r.width || 1) / (r.height || 1);
  camera.updateProjectionMatrix();
}
function buildTimeline() {
  ctx && ctx.revert();
  ctx = gsap.context(() => {
    const s2 = Flip.getState(".second .marker");
    const s3 = Flip.getState(".third .marker");
    const tl = gsap.timeline({
      scrollTrigger: {
        start: 0,
        end: "max",
        scrub: 2
      }
    });
    tl.add(Flip.fit(canvasEl, s2, { duration: 1, ease: "none" }), 0).to(
      mesh.rotation,
      { x: `+=${Math.PI}`, y: `+=${Math.PI}`, duration: 1, ease: "none" },
      "<"
    ).addLabel("mid", "+=0.5").add(Flip.fit(canvasEl, s3, { duration: 1, ease: "none" }), "mid").to(
      mesh.rotation,
      { x: `+=${Math.PI}`, y: `+=${Math.PI}`, duration: 1, ease: "none" },
      "<"
    );
  });
}
function build() {
  ctx && ctx.revert();
  const start = document.querySelector(".container.initial");
  if (!canvasEl) {
    canvasEl = document.createElement("canvas");
    canvasEl.className = "box";
    start.appendChild(canvasEl);
    initThree(canvasEl);
  } else {
    buildTimeline();
  }
}
build();
addEventListener("resize", () => {
  onResize();
  buildTimeline();
});

<!--
